3. NGui Explained

You can use the NGui class to do GUI stuff for you.

Declare some variables and frames. Attach those to appropriate structure and boom!!! NGui interface will be ready for you.

Modify as you need to change the appearance.

Bind appropriate methods to run the tasks when an event is called.

Follow Below steps in order to create your own GUI Frames in Python using Nettoolkit interface hooks.
Backend Credit: PySimpleGUI

Define a few functions which will return Frames.

# -----------------------------------------------------------------------------------
#  Import form items from nettoolkit
# -----------------------------------------------------------------------------------
import PySimpleGUI as sg
from nettoolkit.nettoolkit.forms.formitems import *

# -----------------------------------------------------------------------------------
#  Define all your frames here
# -----------------------------------------------------------------------------------

## This is frame 1 of group1
def group1_frame1():
    return sg.Frame(title=None,
                    relief=sg.RELIEF_SUNKEN,
                    layout=[

        [sg.Text('Group1 - Frame1 Contents and your frame items will go here...'),],
        under_line(80),
        [sg.Button("Click to run", change_submits=True, key='btn1')],
        under_line(80),
        ])


## This is frame 2 of group1
def group1_frame2():
    return sg.Frame(title=None,
                    relief=sg.RELIEF_SUNKEN,
                    layout=[

        [sg.Text('Group1 - Frame2 Contents and your frame items will go here...'),],
        under_line(80),
        [sg.Checkbox('Event which trigger some field update', key='cb1', change_submits=True)],
        [sg.Text("Field which will be updated by below trigger"),sg.InputText(key='txt1')],
        under_line(80),
        ])

## This is frame 1 of group2
def group2_frame1():
    return sg.Frame(title=None,
                    relief=sg.RELIEF_SUNKEN,
                    layout=[

        [sg.Text('Group2 Contents and your frame items will go here...'),],
        under_line(80),
        [sg.Button("Click to run", change_submits=True, key='btn2')],
        under_line(80),
        ])


## ... Define more as needed

Now pick EVENT_UPDATORS, EVENT_ITEM_UPDATORS, RETRACTABLES outof these.

EVENT_UPDATORS: keys which will trigger an event function.
EVENT_ITEM_UPDATORS: keys which will trigger and event function which results change in a form object.
RETRACTABLES: keys which values needs to be cleaned up when “Clean” button pressed.

# ---------------------------------- #
#         EVENT UPDATERS             #
# ---------------------------------- #

# ---------------------------------------------------------------------------------------
#   list down variables which triggers an event function call -- exec_fn(i)
# ---------------------------------------------------------------------------------------
EVENT_UPDATERS1 = { 'cb1'}
EVENT_UPDATERS2 = set()

# --------------------------------- [ Club ] --------------------------------------------
EVENT_UPDATORS = set()
EVENT_UPDATORS = EVENT_UPDATORS.union(EVENT_UPDATERS1)
EVENT_UPDATORS = EVENT_UPDATORS.union(EVENT_UPDATERS2)
# ---------------------------------------------------------------------------------------

# --------------------------------------- #
#         EVENT ITEM UPDATERS             #
# --------------------------------------- #

# ---------------------------------------------------------------------------------------
#   list down variables which triggers an item update event function -- exec_fn(obj, i)
# ---------------------------------------------------------------------------------------
EVENT_ITEM_UPDATORS = set()


# ---------------------------------- #
#        RETRACTABLE KEYS            #
# ---------------------------------- #

# ---------------------------------------------------------------------------------------
#  sets of retractable variables , which should be cleared up on clicking clear button
# ---------------------------------------------------------------------------------------
G1_RETRACTABLES = set()
G2_RETRACTABLES = { 'txt1', }

# --------------------------------- [ Club ] --------------------------------------------
RETRACTABLES = set()
RETRACTABLES = RETRACTABLES.union(G1_RETRACTABLES)
RETRACTABLES = RETRACTABLES.union(G2_RETRACTABLES)
# -------------------------------------------------------------------------

Set Button Pallete, to differenciate the Frames between button clicks.

# ---------------------------------------------------------------------------------------
#  Necessary Project imports
# ---------------------------------------------------------------------------------------
from collections import OrderedDict

# ---------------------------------------------------------------------------------------
#  Create Frame groups and ascociate frame descriptions for each frames definition to it
# ---------------------------------------------------------------------------------------
GROUP1_FRAME = {
    'G1_Frame1_Description': group1_frame1(),
    'G1_Frame2_Description': group1_frame2(),
}
GROUP2_FRAME = {
    'G2_Frame1_Description': group2_frame1()
}
# ... Add more Frame_Groups as necessary

# ---------------------------------------------------------------------------------------
#   Creating 'Buttons' and ascociate each with a group name
# ---------------------------------------------------------------------------------------
BUTTUN_PALLETE_DIC = OrderedDict()
BUTTUN_PALLETE_DIC["btn_grp_1"] = {'key': 'btn1',  'frames': GROUP1_FRAME,  "button_name": "Group1 Frames"}
BUTTUN_PALLETE_DIC["btn_grp_2"] = {'key': 'btn2',  'frames': GROUP2_FRAME,  "button_name": "Group2 Frames"}
# ... Add more buttons as necessary

Event Functions.

Here are few EVENT_UPDATORS functions and EVENT_ITEM_UPDATORS functions.

# ================================================================================
#  // EVENT_ITEM_UPDATORS //
#    these functions will accept two arguments. first is NGui object iself and
#    second will be [i] item list of object
# ================================================================================

def g1_f2_cb1_executor(obj, i):
    s = "You have presesed a button from Group 1 Frame 2, text box value will be append with X"
    print(s)
    new_text = i['txt1'] + "X"
    obj.event_update_element(txt1={'value': new_text})

# ================================================================================
#  // EVENT_UPDATORS //
#   Such functions will accept only [i] item list of NGui object.
# ================================================================================

def g1_f1_btn1_executor(i):
    ## Your execution code will reside here ##
    s = "You have presesed a button from Group 1 Frame 1"
    print(s)
    sg.Popup(s)

def g2_f1_btn2_executor(i):
    ## Your execution code will reside here ##
    s = "You have presesed a button from Group 2 Frame 1"
    print(s)
    sg.Popup(s)

#  // Tie all these functions together to appropriate keys of Frames //

EVENT_FUNCTIONS = {
    'cb1' : g1_f2_cb1_executor,
    'btn1': g1_f1_btn1_executor,
    'btn2': g2_f1_btn2_executor,
}

We are all set, Get Ready For The Show. Its time to tie all above together.

# --------------------------------------------
# IMPORT NGui
# --------------------------------------------
from nettoolkit import NGui

# ----------------------------------------------------------------------------------
#  Create an Instance of NGui
#  Options can be sent while object initialization or can be set as propery as well
#  after instance is created.
# ----------------------------------------------------------------------------------
NG = NGui(
    header = "My Custom Project - X",
    banner = "Project X - Which does something",
    form_width = 800,
    form_height = 400,
    event_updaters      = EVENT_UPDATORS,
    event_item_updaters = EVENT_ITEM_UPDATORS,
    retractables        = RETRACTABLES,
    event_catchers      = EVENT_FUNCTIONS,
    button_pallete_dic  = BUTTUN_PALLETE_DIC,
)

# ----------------------------------------------------------------------------------
#  Optional: Define maximum Buttons in a row in button pallete. (if more buttons)
# ----------------------------------------------------------------------------------
NG.max_buttons_in_a_row = 6

# ----------------------------------------------------------------------------------
#  Call for an instance, by providing optional initial frame group definition
#  no initial frame group will show all frames at initialization
# ----------------------------------------------------------------------------------
NG('btn_grp_1')

Important

Parameters for NGui

header (string) Header for the window (default: None)
banner (string) Banner to display in window (default: None)
form_width (integer) Form width (default: 700)
form_height (integer) Form Height (default: 1440)
event_updaters (set) Set of event updator element keys (default: None)
event_item_updaters (set) Set of event item updator element keys (default: None)
retractables (set) Set of element keys which can be cleanup when pressing clean button.
event_catchers (set) Dictionary of event function keys and its respective functions (default: None)
button_pallete_dic (dict) Dictionary which defines Button pallete buttons ( Default: None )
max_buttons_in_a_row (int) maximum Buttons in a row in button pallete. (if more buttons)

Note

Parameters for NGui

All these arguments are optionals to declare whilst creating the object instance. And can be later define by propery assignment ( ex: NG.header = “Some header” ).
Although all of these are optionals to declare at beginning, some of the arguments are required ones to provide before calling the NGui class in order to work properly..
If you call NGui, without providing button_pallete_dic . GUI will rendered with all frames with no buttons on button pallete.
Calling NGui without any initial button key or wrong button key; renders all frames while loading new window.

Decorator @popupmsg()

pre (str, optional): Popup Message to display before function execution. Defaults to None.
post (str, optional): Popup Message to display after function execution. Defaults to None.

from nettoolkit.nettoolkit.forms.formitems import popupmsg

@popupmsg(pre="Popup msg before bfunction run",
            post="Popup msg after function run")
def foo():
    pass

Decorator @activity_finish_popup

This decorator will provide “Activity done.” Popup message once function execution is completed

from nettoolkit.nettoolkit.forms.formitems import activity_finish_popup

@activity_finish_popup
def foo():
    pass
